Standard Keyway for Hobs
bore diameter of gear hobs: 22mm--keyway is 6mm
bore diameter of gear hobs: 27mm--keyway is 7mm
bore diameter of gear hobs: 32mm--keyway is 8mm
bore diameter of gear hobs: 40mm-keyway is 10mm
bore diameter of gear hobs: 50mm--keyway is 12mm
bore diameter of gear hobs: 60mm--keyway is 14mm
other specifications of keyway for hobs can be done according to customer's requirement.
