PA30° DIN5480 Involute Spline Gear Hob with Module m3.5
2022-06-01 08:44:07
jiangxingTools
2384
PA30° DIN5480 Involute Spline Gear Hob with Module m3.5
Tooth profile：GB, DIN5480 standard
Material：HSS M2, M35,ASP2052, S390
Accuracy：AA, A DIN3968
Hob sizes：OD 70 * Length 70 * Bore 27mm
Module m3.5, with pressure angle PA30°
